AIRCRAFT PARTS
Aircraft Pressure Gauges
| Product Code | Voltage | Diameter | Range | Signal | Resistance | Line | Design |
|---|---|---|---|---|---|---|---|
| ID61.6346.14 | 12–24V | Ø52 mm | 0–4/4 | CAN-Bus | – | Top Line | FR black |
| ID61.6346.34 | 12–24V | Ø52 mm | 0–4/4 | CAN-Bus | – | Top Line | FR chrome |
| MD51.2120.21 | 12V | Ø52 mm | 0–1/2–1 | Analog | 3–180 Ω | Marine Line | FR black |
Aircraft Pressure Gauges
Reliable Pressure Monitoring for Demanding Environments
Our pressure gauge is meticulously engineered to deliver accurate, repeatable, and reliable pressure measurements in both industrial and aviation environments. Designed to meet the demanding requirements of professionals, this gauge is built with premium-grade materials that ensure long-term durability, resistance to corrosion, and optimal performance even in the most challenging conditions. Whether it’s exposure to vibration, high temperatures, or fluctuating pressure levels, the construction and calibration of this instrument are aligned with internationally recognized standards, providing dependable readings you can trust.
From high-precision laboratory setups to rugged field operations, the pressure gauge adapts seamlessly to a variety of uses. It is ideally suited for monitoring fluid and gas pressure in fuel delivery systems, hydraulic machinery, and pneumatic applications—where real-time data and operational safety are critical. The analog version features a clear, easy-to-read dial, available in single or dual-scale formats (e.g., bar/psi), and can be filled with glycerin to dampen needle oscillations in high-vibration settings. For those requiring more advanced monitoring capabilities, the digital model offers a backlit display and optional signal outputs for integration with electronic systems, such as SCADA or cockpit displays.
Ease of installation is a key feature of this gauge, thanks to its wide range of mounting options (including panel, flush, and rear-thread configurations), as well as compatibility with standard process connections like 1/4″ NPT and BSP. With multiple pressure ranges available and customizable configurations on request, the device can be tailored to suit specific operational needs across sectors such as aviation, marine, automotive, energy, and industrial automation.
Professionals rely on our pressure gauges not only for their precision but also for the peace of mind that comes with using an instrument built to withstand extreme conditions without compromising accuracy. It’s more than a measurement tool — it’s a trusted component in your system’s safety and performance.
“Pressure accuracy is absolutely critical in our aviation maintenance operations. We’ve tested numerous gauges, and this one stands out for its stability under vibration and quick, precise readings. It’s built like an instrument, not just a tool.”
Contact With Us
Let’s Work Together?
Delivering high-quality parts and components for the aviation, maritime, automotive, and heavy industries. Ensuring reliability and precision in every product.
Have Any Question?
+48 516 494 849
Send Email
contact@e-worldparts.com
Contact Us
Questions & Answers
What types of pressure media is the gauge compatible with?
Our pressure gauge is compatible with air, oil, fuel, hydraulic fluids, and most non-corrosive gases and liquids. For aggressive media, we offer specialized materials on request.
Can the gauge be used in high-vibration environments?
Yes. The analog version is available with a glycerin-filled case, which dampens needle movement in high-vibration areas such as aircraft engines or heavy machinery.
What pressure ranges are available?
We offer a wide selection of pressure ranges, from as low as 0–1 bar (0–15 psi) up to 0–400 bar (0–6000 psi). Custom ranges can be configured for bulk or OEM orders.
Is this gauge suitable for aviation use?
Absolutely. It’s designed with aviation-grade reliability and is used in both general aviation and experimental aircraft for monitoring fuel, oil, and hydraulic pressures.
Does the digital model offer output for data logging?
Yes. The digital version can be equipped with optional signal outputs (e.g., 4–20mA, 0–10V, RS232) for integration into logging, monitoring, or automation systems.
Precision Under Pressure: Introducing the Aircraft Pressure Gauge
Embark on a journey of control and confidence with our cutting-edge aircraft pressure gauge solutions. Built for modern aviation and industrial applications, these instruments are engineered to provide uncompromising accuracy and long-term stability. Whether monitoring hydraulic circuits in light aircraft or ensuring safe pressure levels in critical ground systems, our gauges deliver clear, reliable readings in real time—empowering professionals to make informed decisions at every altitude.
Revolutionizing Instrumentation: Digital Pressure Gauge Integration
Step into the next generation of system monitoring with seamless digital pressure gauge integration. Designed for compatibility with both legacy and advanced avionics setups, our pressure gauges offer crisp displays and responsive measurements across a variety of systems. Say goodbye to outdated dials and guesswork—our digital solutions deliver real-time pressure intelligence with unmatched clarity and precision, streamlining operations and boosting confidence in high-performance environments.
Elevating Precision and Reliability in Pressure Management
- Real-Time Monitoring: Our pressure gauges provide continuous, high-accuracy feedback, giving pilots and engineers the data they need to maintain system integrity at all times.
- Extreme Condition Performance: Designed to withstand vibration, temperature variation, and altitude shifts, our gauges are built for the demanding conditions of aviation and industrial environments.
- Easy Integration: With both analog and digital models available, our pressure gauges fit seamlessly into any panel, instrument cluster, or monitoring system.
- Safety and Compliance: Calibrated to international standards, our pressure gauges help meet safety regulations and reduce the risk of overpressure incidents or system failures.
Precision Across a Wide Range
Offers reliable measurements from low-pressure to high-pressure systems, supporting diverse applications like hydraulics, pneumatics, and fuel monitoring.Compact and Lightweight Design
Engineered for space-constrained environments, ensuring easy installation in panels, cockpits, and instrument clusters.User-Friendly Readability
Large-scale markings, anti-glare displays, and backlighting options ensure readability even in low-light or direct sunlight.Zero Drift Technology
Minimized long-term calibration drift provides stable and dependable readings over thousands of operational hours.Low Power Consumption
Digital variants are optimized for minimal power draw, crucial for battery-sensitive or autonomous system designs.Fail-Safe Operation
Includes built-in overpressure protections and failure indicators, ensuring the gauge provides dependable feedback under all scenarios.
Redefining Pressure Monitoring with Advanced Gauge Technology
Engineered for Accuracy: Our pressure gauges use premium sensor technology to ensure precise, repeatable results across a wide pressure range.
Digital and Analog Options: Choose between traditional analog formats for visual simplicity or digital displays for advanced integration and feedback.
Customizable and Scalable: Whether for single-engine aircraft or multi-system industrial use, our gauges can be tailored to meet specific operational needs.
Built to Last: Shock-resistant casings, corrosion-resistant internals, and vibration-damping designs ensure longevity and reliability under all conditions.
Smart Diagnostics
Advanced models include onboard diagnostics and error codes, streamlining maintenance and reducing downtime.Multi-Environment Compatibility
Suitable for both cabin-pressurized aircraft and unpressurized systems, as well as stationary industrial equipment.Mounting Versatility
Designed for panel mount, flush mount, or external bracket mounting depending on installation needs.Configurable Alerts
Digital models offer programmable pressure thresholds with visual or audible alerts for real-time feedback.Data Logging Capability
Optional data logging functionality enables pressure trend analysis and predictive maintenance scheduling.Global Support and Documentation
All models include multilingual manuals, universal symbols, and access to global support for integration and servicing.
Enhancing System Control: The Promise of Precision Pressure Gauges
At the core of our pressure gauge technology lies a commitment to control, safety, and precision. These instruments are more than just measurement tools—they’re essential components in the safe operation of aircraft, engines, and critical mechanical systems. With real-time data, robust construction, and seamless integration, our gauges empower users to detect anomalies early, prevent failure, and optimize performance across every phase of flight or production.
Setting the Benchmark in Pressure Monitoring Technology
Join the forefront of precision instrumentation with our advanced pressure gauge technology. Combining aerospace-grade engineering with intuitive operation, our solutions deliver unmatched clarity, responsiveness, and reliability. From cockpit panels to industrial control rooms, our gauges are trusted worldwide by professionals who demand the highest standards in accuracy and durability.
Pressure Gauge – Key Features
| Feature | Description | Benefit |
|---|---|---|
| Measurement Range | 0 to 5000 PSI / 0 to 350 bar | Wide applicability across aviation and industrial pressure systems |
| Accuracy | ±1% of full scale | Precise monitoring for critical systems and high safety margins |
| Display Type | Analog / Digital LCD | Easy-to-read, reliable output for any cockpit or control panel |
| Response Time | <1 second | Instantaneous feedback for real-time decision-making |
| Input Compatibility | 4-20mA, Voltage, CAN bus | Seamless integration with modern avionics and industrial controllers |
| Power Consumption | 1 to 4 Watts | Low energy draw for enhanced system efficiency |
| Operating Temperature Range | -40°C to 85°C | Consistent performance in extreme thermal environments |
| Vibration Resistance | MIL-STD compliant | Withstands turbulence and harsh industrial conditions |
| Certification | FAA, EASA, ISO 9001 | Meets aviation and international industry standards |
| Additional Features | Overpressure protection, configurable alerts, logging | Enhanced safety, diagnostics, and operational traceability |
Explanation of Key Features:
- Measurement Range:
The pressure gauge supports a wide range of pressure measurements from 0 to 5000 PSI (or 0 to 350 bar), making it versatile for various systems such as hydraulics, pneumatics, and fuel lines in both aircraft and industrial applications. - Accuracy:
With a high accuracy of ±1% full scale, the pressure gauge ensures dependable readings. This is crucial for monitoring critical pressure parameters and maintaining safety in pressurized systems. - Display Type:
Available in both analog dial and digital LCD formats. Analog provides intuitive quick-glance readings, while digital ensures precision and easier data interpretation with options like backlighting and numeric alerts. - Response Time:
A response time of under 1 second guarantees real-time data visualization, enabling timely actions in systems where pressure can change rapidly. - Input Compatibility:
Supports multiple signal types including 4–20mA, voltage, and CAN bus, making the gauge compatible with legacy systems as well as next-gen aircraft and industrial control units. - Power Consumption:
Consumes only 1 to 4 Watts, preserving battery life and reducing overall energy load in aircraft and embedded monitoring systems. - Operating Temperature Range:
Operates reliably in temperatures from -40°C to 85°C, ideal for use in both high-altitude aircraft and ground-based equipment exposed to extreme climates. - Vibration Resistance:
Designed to meet MIL-STD vibration requirements, this gauge remains accurate and stable even in environments with constant motion or shock loads. - Certification:
Fully compliant with aviation safety standards (FAA, EASA) and quality management systems (ISO 9001), ensuring airworthiness and operational confidence. - Additional Features:
Includes overpressure protection mechanisms, configurable alert thresholds, and data logging capabilities—allowing users to maintain system integrity, track anomalies, and analyze historical pressure trends.
